Description
| Pixel Pitch | P2.5 | P2.5 | P2.5 |
| Led Lamp Bead Model | SMD1415 | SMD1415 | SMD1415 |
| Module Reslution(W*H) | 80×80 | 80×80 | 80×80 |
| Moudle Size(W*H) | 200x200mm | 200x200mm | 200x200mm |
| Cube Reslution(W*H) | 80x80x80dot | 160x160x160dot | 240x240x240dot |
| Panel Size(W*H*D) | 200x200x200mm | 400x400x400mm | 600x600x600mm |
| Module Quantity(W*H) | 1pcs/side | 4pcs/side | 9pcs/side |
| Weight(kg/Cube) | 5.5kg | 25kg | 60kg |
| Material | lron | ||
| Fixed Way | Rear Access(Screw) | ||
| Brightness(cd/m²) | 6000 | ||
| Protection Level | Ip65 | ||
| Screen Design | 5 sided/4sided(optional) | ||
| Maintenance Way | Rear | ||
| Driving Method | Static Constant Current Drive | ||
| Frame Change Frequency | 60 | ||
| Refresh Rate | 1920-3840 | ||
| Color Temperature | 2000K~9500K | ||
| Control Method | WIFI/4G | ||
| Operating Voltage | AC:100V~240V、50~60Hz | ||
| Maximum Power(W/m²) | 700 | ||
| Average Power(W/m²) | 200 | ||
| Continuous Working Time | >7x24hrs | ||
| Service Life | 100000Hours | ||
| Operating Environment | 0°C~40°C 35%~85% | ||
