Description
Specifications
| Feature | Value |
|---|---|
| Pixel Pitch (mm) | 6.94 |
| Panel Size (mm) | 500 × 1000 × 65 |
| Cabinet Weight | ~11.5 kg |
| Brightness (nits) | 6500 – 8000 (adjustable) |
| Contrast Ratio | 8000:1 |
| Refresh Rate | 3840 Hz |
| Frame Frequency | 60 Hz |
| Viewing Angle (H/V) | 160° / 140° |
| Power Consumption | Avg: 220 W/m² / Max: 650 W/m² |
| IP Rating | IP65 (Front & Rear) |
| Serviceability | Full Front Maintenance |
| Operating Temp | –20 °C to +50 °C |
| Operating Humidity | 10 – 90 % RH |
| Lifetime | 100,000 hrs |
